Function Description
The ESA S860W is used for advanced CNC press brake control. It can manage multiple machine axes, including ram synchronization, multi-axis backgauge movement, CNC crowning, sheet follower control, and additional auxiliary axes depending on machine configuration.
As a Windows-based controller, the S860W provides a more powerful operation platform and improved usability compared with older controller generations. It is suitable for high-end CNC press brakes that need accurate bending control and efficient production management.
Applicable Machine
CNC Press Brake, Hydraulic Press Brake, Electric Press Brake, Hybrid Press Brake
Technical Parameters
| Parameter |
Specification |
| Product Name |
ESA S860W |
| Product Type |
Windows CNC Press Brake Controller |
| Replacement Model |
ESA S660W |
| Controller Version |
Windows version |
| Applicable Machine |
CNC hydraulic press brake |
| Standard Axis Configuration |
12+1 axis |
| Typical Axis Control |
Y1, Y2, X1, X2, R1, R2, Z1, Z2 and auxiliary axes + CNC crowning |
| Crowning Control |
Supported |
| Backgauge Control |
Advanced multi-axis backgauge control |
| Sheet Follower Control |
Available depending on machine configuration |
| Auxiliary Axis Control |
Supported depending on machine configuration |
| Programming Type |
Advanced CNC bending programming |
| Operation Interface |
Windows-based operating interface |
| Machine Level |
High-end CNC press brake |
| Typical Application |
Precision bending and complex forming |
| Main Advantage |
12+1 axis control, Windows platform, advanced bending management |
Application Scenarios
The ESA S860W is suitable for high-end precision sheet metal manufacturing, complex bending parts, electrical cabinets, elevator panels, stainless steel panels, automotive components, machinery covers, industrial enclosures, and advanced equipment manufacturing.
It is recommended for users upgrading from ESA S660W or configuring a high-end 12+1 axis CNC press brake.
Compatible Models
The ESA S860W is suitable for high-end precision sheet metal manufacturing, complex bending parts, electrical cabinets, elevator panels, stainless steel panels, automotive components, machinery covers, industrial enclosures, and advanced equipment manufacturing.
It is recommended for users upgrading from ESA S660W or configuring a high-end 12+1 axis CNC press brake.
FAQ
Q1: What does “W” mean in ESA S860W?
A: The “W” means Windows version. ESA S860W is a Windows-based CNC press brake controller designed for high-end multi-axis bending applications.
Q2: Which model does the ESA S860W replace?
A: The ESA S860W is used as a replacement for the ESA S660W. It provides an upgraded Windows-based control solution for high-end CNC press brakes.
Q3: How many axes does the ESA S860W support?
A: The ESA S860W is commonly configured as a 12+1 axis controller. The actual axis configuration depends on the machine design, backgauge system, crowning system, sheet follower, and auxiliary axis requirements.
